€494,00
Add to cart

25.994

25.994
€494,00
* Excl. tax Excl. Shipping costs
Article number:
25994-500
Weight:
21kg
Delivery time:
From stock

UKB-System Trumpf/ Bystronic - Flattening dies Read more..

From stock
  • Quality

    use of the optimum materials
  • Consultation

    competent and qualified advice
  • Accessibility

    reliable clearing and delivery
  • Know-how

    more than 30 years of experience

Information

 25.994


Tooling system UKB-System Trumpf/ Bystronic
U-opening U = 10,2 mm
Intake radius R = 1 mm
Height
100 mm
Load 500 kN/m max.
Material C45 tempered to 800-850N/mm²


Max. 1,8 mm material thickness
Rm = 400 N/mm2

For flattening/hemming punch/top-tool 15.904 (UKB-System Trumpf) and 14.910 (UKB-System Bystronic)





Tool lengths


DIES


500 mm 300 mm 200 mm 100 mm
Dies lenght 500 mm Dies lenght 300 mm Dies lenght 200 mm Dies lenght 100 mm

550 mm sectionalized

Sectionalized dies are delivered as a
     complete set

9 Segments

Dies lenght 550 mm sectionalized


Put together your tool lenghts individually!
Offers for sets 1050 / 2050 / 3050 / 4050 mm, contact us!






Related products

15.904

UKB-System Trumpf - 24° Flattening punches/top tools
€492,00
* Excl. tax Excl. Shipping costs

14.910

UKB-System Bystronic - 24° Flattening punches/top tools
€584,00
* Excl. tax Excl. Shipping costs

25.992

UKB-System Trumpf/ Bystronic - Flattening dies
€494,00
* Excl. tax Excl. Shipping costs

15.902

UKB-System Trumpf - 24° Flattening punches/top tools
€492,00
* Excl. tax Excl. Shipping costs

14.908

UKB-System Bystronic - 24° Flattening punches/top tools
€584,00
* Excl. tax Excl. Shipping costs

25.995

UKB-System Trumpf/ Bystronic - Flattening dies
€494,00
* Excl. tax Excl. Shipping costs

15.905

UKB-System Trumpf - 24° Flattening punches/top tools
€492,00
* Excl. tax Excl. Shipping costs

14.912
