Home / 25.304
€272,00
Add to cart

25.304

25.304
25.304
€272,00
* Excl. tax Excl. Shipping costs
Article number:
25304-500
Weight:
7.3kg
Delivery time:
From stock

UKB-System Trumpf - 84° dies, H = 100 mm Read more..

Video
Download DXF
From stock

  • Quality

    use of the optimum materials

  • Consultation

    competent and qualified advice

  • Accessibility

    reliable clearing and delivery

  • Know-how

    more than 30 years of experience

Information

 25.304


Tooling system UKB-System Trumpf/Wila/Bystronic
Angle 84°
Die opening V = 12 mm
Intake radius R = 1 mm
Height 100 mm
Load 400 kN/m max.
Material C45, 650 - 800 N/mm2





Tool lengths




DIES








500 mm    300 mm   200 mm   100 mm
Matrizen lengte 500 mm   Matrizen lengte 300 mm   Matrizen lengte 200 mm   Matrizen lengte 100 mm







550 mm sectionalized

Sectionalized dies are delivered as
    a complete set

9 Segments



 Matrizen lengte 550 mm



2050 mm Tool Set

14 Segments

3050 mm Tool Set

16 Segments

4050 mm Tool Set

18 Segments

Put together your tool lenghts individually!



Matrizen Länge 300 mm



Specifications
