€270,00
Add to cart

15.310

15.310
15.310
€270,00
* Excl. tax Excl. Shipping costs
Article number:
15310-500
Weight:
12kg
Delivery time:
From stock

UKB-System Trumpf - Punches/top-tools H = 120 mm Read more..

From stock
  • Quality

    use of the optimum materials
  • Consultation

    competent and qualified advice
  • Accessibility

    reliable clearing and delivery
  • Know-how

    more than 25 years of experience

Information

 15.310


Tooling system UKB-System Trumpf/Wila/LVD
Angle 60°
Radius R 4,0 mm
Height 120 mm
Load 1300 kN/m max.
Material 42 CrMo4, tempered to 1100 – 1200 N/mm2




further radii
 R (mm)  H (mm)
2,0 119,8
2,5 119,2
3,0 119,0
5,0 118,8
6,0 118,2

Prices and other radii on demand
Delivery time 1–3 working days




Tool lengths

PUNCHES/TOP TOOLS WITH SIMPLE CLAMP

Length 500 mm

Length 300 mm

Length 200 mm

Length 100 mm

Punch/top tools length 500 mm

Punch/top tools length 300 mm

Punch/top tools length 200 mm

Punch/top tools length 100 mm

Length 550 mm sectionalized

Sectionalized punches/top tools are delivered as a complete set

10 Segments, with Simple Clamp and horn extension left and right

Punch/top tools length 550 mm sectionalized



Related products

15.680

UKB-System Trumpf - Punches/top-tools H = 158 mm
€598,00
* Excl. tax Excl. Shipping costs

15.730
